Fixed Scanning Laser Gas Monitor: A Solid Guarantee for Industrial Safety

In the complex industrial environment, safety is always of paramount importance. The fixed scanning laser gas monitor TS1101 from Anhui Cen Feng Technology is becoming a crucial force in ensuring industrial safety.

The TDLAS laser absorption spectroscopy technology adopted by the TS1101 is one of its core advantages. With this technology, it can measure the gas concentration at multiple preset positions in the workplace in a fixed installation and automatic scanning manner through non-contact measurement. In large petrochemical plants, whether it is around the towering gas storage tanks or near the intricate pipeline networks, it can accurately capture the changes in gas concentration. Moreover, the function of combining real-time video images makes gas leakage impossible to hide and can quickly locate the approximate leakage position, providing key clues for subsequent processing.

The integrated design is a highlight of the TS1101. It integrates the gas detector, high-definition camera, and all-directional variable-speed pan-tilt into one. There are no external connection cables between the devices, which not only makes the appearance concise but also avoids the potential failure risks caused by messy wiring. In terms of access, it adopts a standard communication protocol. Whether it is data transmission with the upper computer or cooperation with the control system and auxiliary equipment, it can be easily realized, greatly enhancing its adaptability in different industrial scenarios.

In terms of safety performance, the TS1101 has reached the industry-leading level. The explosion-proof design, wide voltage working range, and surge protection function enable it to cope with the complex and changeable industrial electrical environment. Its explosion-proof grade of Ex db IIC T6 Gb/Ex tb IIIC T80℃ Db and protection grade of IP68 provide powerful protection capabilities for the equipment in the flammable and explosive industrial sites. It is worth mentioning that the detection laser belongs to Class I laser, and operators do not need to worry about the laser causing harm to their eyes, ensuring personal safety during use.

In terms of performance parameters, the TS1101 performs outstandingly. The detection range of 360° horizontal rotation and ±90° pitch realizes all-round and dead-angle-free monitoring. It can detect a variety of gases, such as the common methane (CH4), and can also be customized to detect gases such as CO, NH3, and C2H4 according to user needs. The detection range is (0 - 50000) ppm*m, and the measured distances are 0 - 150m and 0 - 200m. The sensitivity is as high as 5 ppmm, and the response time is ≤0.1s. It can detect tiny gas leaks in a very short time, buying precious time for timely treatment.

In terms of mechanical indicators, the TS1101 is also reliable. The standard shell material is 304 stainless steel (316L is optional), which is sturdy and durable and can resist physical impacts and chemical corrosion in the industrial environment. The number of preset positions is 128, and the preset position accuracy is ≤0.1°. The electrical interface is G3/4 external thread. These designs provide strong support for easy installation and accurate monitoring.

Its operating environmental conditions are wide. The atmospheric pressure is between (80 - 110) kPa, the ambient temperature range is -40℃ - +60℃, and the relative humidity is ≤95%RH (+25℃). It can operate stably in high-temperature, low-temperature, or high-humidity environments.

In practical application scenarios, the TS1101 plays an irreplaceable role. In the storage and irrigation area, it is always vigilant about the safety of the gas storage tanks and will immediately alarm and locate once there is a leak. In the production workshop, the tiny leaks at the complex pipeline connections and valves cannot escape its "eyes". In the loading and unloading area, it monitors the surrounding environment in real time when the vehicle is loading and unloading gas to prevent accidents.

In conclusion, the fixed scanning laser gas monitor TS1101 has become a powerful assistant in guarding industrial safety in many industries such as petroleum, petrochemical, natural gas, chemical, mining, and power plants with its advanced technology, excellent performance, and reliable quality, providing a solid guarantee for the safe and stable operation of industrial production.
